NAD: VH f-ing 4 content!!! Tube help plz!!

  • Thread starter Thread starter Ricky Rockhardo
  • Start date Start date
Ricky Rockhardo

Ricky Rockhardo

Active member
I got her about a week ago off of someone on Reverb. As you can see from the pic she is not a case queen so I may get the headshell re-tolexed. But dear lord, this amp is all I imagined and more. Haven’t touched ch4 yet. I’m surprised how much I love ch2. It’s like what I always wanted out of a JCM 800. Ch3…. Words don’t do it justice.


I believe she’s a 2009 since the handwritten serial # starts with 09. Came with Tung Sol 6550s and the tube switch is labeled 6550/EL34. I’m planning on getting a new set of power tubes and would greatly appreciate your advice. I was thinking of staying with 6550s since I’ve never had an amp with them, but I am concerned they might be damaging in the long run and perhaps I should go the KT77 route. Thoughts?

Lastly, the poor chassis has a bit of dust/oxidation on the top. Do you all have any recommendations for cleaning it up?

Thanks to all and Peter in particular for this wonderful gift of tone 😁

Congrats!

I like to use a Horizon Devices Precision drive on channel 2. Takes it to a whole other dimension

I love channel 4 for smooth silky leads that flow . It’s never mentioned but wow it’s maybe the best channel for solos ever

If you want to go with current 6550 I've always liked the sovtek 6550WE in the VH4
Tung Sol's are a bit too hifi sounding IMO 6550's are ok if biased a bit cold.

Lots of other tube choices, nothing sounds bad in a VH4 just different/

Favorites of mine are
JJ 6L6
GL KT77 ( much better than the JJ IMHO )
TAD EL34 BSTR

For cleaning up the oxidization , try a damp cloth then dry it, if its still not clean use a dab of oil ( wd40, Deoxit ) on a rag and wipe it off afterwards.

Congrads on one of the best amps ever designed!

Last edited:
MesaSean said:
Congrats!

I like to use a Horizon Devices Precision drive on channel 2. Takes it to a whole other dimension
Click to expand...
I have yet to boost ch 2. It just sounds soooo good as is, but I could see just a little bit more gain taking the sound to 11

rickenbacker198 said:
If you want to go with current 6550 I've always liked the sovtek 6550WE in the VH4
Tung Sol's are a bit too hifi sounding IMO 6550's are ok if biased a bit cold.

Lots of other tube choices, nothing sounds bad in a VH4 just different/

Favorites of mine are
JJ 6L6
GL KT77 ( much better than the JJ IMHO )
TAD EL34 BSTR

For cleaning up the oxidization , try a damp cloth then dry it, if its still not clean use a dab of oil ( wd40, Deoxit ) on a rag and wipe it off afterwards.

Congrads on one of the best amps ever designed!
Click to expand...
Thanks for the recommendations!

I like my Ch 4 with the gain about 11 o'clock and the channel Volume cranked up high about 3-4 o'clock. I find it a bit too compressed and saturated if the gain knob is too high, for my ear.

@rickenbacker198 : How would you describe the 6550's against the 6L6's and KT77's?
I have one VH4 with 6L6 (MSTR) and another with KT77's (GL) so I can relate between them.

Hard to describe!!

I’ve tried 3 kinds of 6550 ,
Overall they’re more dynamic and full range then any KT77, EL34 , 6L6.
The 6550’s can be sound a little bloated if your used to EL34’s. I like 6L6 the best overall in my particular VH4.

I found Tung Sols Hifi , harder with more highs/ lows and less mid.

The Sovtek 6550we are full sounding ,have good bass and a slightly rolled off treble, maybe the smoothest of them all. Nice tube for guitar frequencies.

The Wing C was the most dynamic, almost explosive! while still being full / warm sounding.
These were standard for a while in Diezel amps. If you ever have the chance to get a set $$, you’ll see why.

Sweet, thanks!

I was used to the KT77's as my standard but I really love how the 6L6's sound now I've heard them in there. I guess my ear prefers their inherent sound after so long with just EL34/KT77's. I've always been interested in the 6550's but I'm hesitant due to Peter's reluctance to their use. I guess if they are biased colder the extra heat shouldn't be as much a factor? I usually like my tubes biased colder anyway, I prefer the higher headroom and less squish that it brings. Hotter bias sounds way too compressed and squishy, esp at cranked volumes. To me.

Philhouse said:
Sweet, thanks!

I was used to the KT77's as my standard but I really love how the 6L6's sound now I've heard them in there. I guess my ear prefers their inherent sound after so long with just EL34/KT77's. I've always been interested in the 6550's but I'm hesitant due to Peter's reluctance to their use. I guess if they are biased colder the extra heat shouldn't be as much a factor? I usually like my tubes biased colder anyway, I prefer the higher headroom and less squish that it brings. Hotter bias sounds way too compressed and squishy, esp at cranked volumes. To me.
Click to expand...
My ear prefers the same a colder bias , usually 28ma with 6L6. I can’t remember what Peter said exactly , he did give a bias maximum for 6550 somewhere here on the forum.
I’m guessing if you keep the 6550s under ~40ma / tube you’ll be ok.

Hey guys, I have some Jj Kt77s on the way. My VH4 has. 6550/ EL34 switch, so I’m guessing I need to switch to EL34 mode when I drop those in and bias. However, if I ever wanted to try 6L6s or 5881s which way should the switch go?

Thanks!!

Ricky Rockhardo said:
Hey guys, I have some Jj Kt77s on the way. My VH4 has. 6550/ EL34 switch, so I’m guessing I need to switch to EL34 mode when I drop those in and bias. However, if I ever wanted to try 6L6s or 5881s which way should the switch go?

Thanks!!
Click to expand...
I absolutely love 6l6s in all my Diezel amps . It just comes alive for me even more so after that . I honestly do not like the jt77s at all. Almost bland compared to 6l6 in a Diezel. IMO

Do you know what are the optimal volume, pres., deep etc. positions during biasing of a VH4?
I`ve read here in the forum, the presence has also an effect on the threshold of biasing... is it true?

Tu_pe said:
Do you know what are the optimal volume, pres., deep etc. positions during biasing of a VH4?
I`ve read here in the forum, the presence has also an effect on the threshold of biasing... is it true?
Click to expand...
Master at zero, presence and depth to half, no jack connected, but for the speaker!

Last edited:
Does this also apply to the Herbert?
I always kept all eq as is when biasing

shadow070 said:
Does this also apply to the Herbert?
I always kept all eq as is when biasing
Click to expand...
Yes to all amps of all manufacturer actually, the most important is to have the lowest possible amount of audio signal going on the power tube.
