NBD!

[7704A]

I was highly recommended this book as a comprehensive resource on the sort of passive networks in guitar amps. Just got it in the mail, looking forward to reading it! It's old enough that it still has discussions for tube circuits, but new enough to cover transistor circuits as well. Neat! I was going to put this in the tech talk section, but that seems like it's more for questions, builds, etc.



[midnightlaundry]

Nice.
Working on an projects right now?



[NowYou'rePlayingWithPower]

Okay, so 7704A is referencing an oscilloscope? You should check your local library to see if they ever have sales. Got a bunch of old electronics books once for like $1 a piece when they got newer editions of them. Cool stuff. Mostly have used the reference in microcontroller builds, not amps though.



[7704A]

Nice.
Working on an projects right now?

Yup, also just generally trying to learn more.



[rsm]

I think Leo Fender started with this RCA manual:

https://bh.hallikainen.org/uploads/HaroldHallikainen/82AInstructionsRCA.pdf



[7704A]

Okay, so 7704A is referencing an oscilloscope?

Bingo. Tek 7704A. Scored one at a reasonable price, and started accruing modules. Incredible service manual. Love it.

You should check your local library to see if they ever have sales. Got a bunch of old electronics books once for like $1 a piece when they got newer editions of them. Cool stuff. Mostly have used the reference in microcontroller builds, not amps though.

Ooo, I'll keep that in mind! I try to keep my feelers out for recycling opportunities like that. Every now and again I get lucky.



[7704A]

I think Leo Fender started with this RCA manual:

https://bh.hallikainen.org/uploads/HaroldHallikainen/82AInstructionsRCA.pdf

I haven't found that one yet, thanks!
