can someone whip up a wiring diagram for me?

[thefyn]

i haven't installed a guitar with a push pull pot for s few years. I have a 2 conducter pup for the neck, and an old gibson tarback for the bridge that looks like it has 4 wires. 2pairs coming from the tarback like ground and hot.

One ground and a hot for the neck, and two pairs of ground and hot for the bridge.

1 push pull vol and one tone.

Note one of the two pots that are already connected is the vol that I need to switch out for the push pull at the bottom left. Also the neck pickup has a quick connect. It's just a 2 wire ground and hot.

Don't worry, the white pickup surround will not me used...

I've gone to the usual places but none have this specific setup. It's usually a pair of humbuckers than can be split and not one etc.



[thefyn]

Can someone diagram me? I'll send you mind mojo.

Diagram me hard.



[thefyn]



[cardinal]

I'm confused as to what you want. 3-way toggle, 1 volume, 1 tone, push/pull to split the bridge?



[thefyn]

I'm confused as to what you want. 3-way toggle, 1 volume, 1 tone, push/pull to split the bridge?

I want a wiring diagram with a 3 way toggle, 1 tone and 1 push pull vol that splits the bridge.



[cardinal]

http://www.guitarelectronics.com/produc ... ne001.html

Just ignore the coil tap stuff from the neck pickup and pretend the push/pull is on the volume pot.

Here are the Gibson color codes:
http://www.stewmac.com/How-To/Online_Re ... ckups.html



[thefyn]

http://www.guitarelectronics.com/product/WD2HH3T11_01/Guitar-Wiring-Diagram-2-Humbuckers3-Way-Toggle-Switch1-Volume0Tone001.html

Just ignore the coil tap stuff from the neck pickup and pretend the push/pull is on the volume pot.

Here are the Gibson color codes:
http://www.stewmac.com/How-To/Online_Re ... ckups.html

I'll be honest...My eyes crossed comparing the Gibson color codes and the wiring diagram compared to what I have. haha. I'm terrible at this.

Can someone look at what I'm working with and upload a paint diagram for me...Anything.
