stephen sawall
Well-known member
GENERAL SPECIFICATIONS
- Nominal diameter: 305mm/12in
- Power handling: 30W
- Nominal impedance: 8, 16
- Sensitivity: 100 dB
- Chassis type: Pressed steel
- Voice coil diameter: 44mm/1,75in
- Voice coil material: Round copper
- Magnet type: Alnico
- Frequency range: 75Hz-5000Hz
- Resonance frequency: 75Hz
