paulyc":332v8q0c said:
Zach...which piece in your rack does the amp switching ? Is it CAE or something else ? I don't see any speaker simulators or load boxes in there anywhere...is there a cab for each head ? and then cabs for effects ? I know it would be a PITA, but could you give a detailed description of your setup and all the tones you cover ? Anyway to do that with an RSB18R and RSB18F ? Thanks !
The Amp Selector (CAE V.1), is on the very bottom of the rack, seated under the Switcher/Interface-- and provides a load on the UN-selected amps, w/ individual Line level controls for each amp. Each amp is routed to the same middle Dry cabinet, so ONLY 1 amp at a time can be active. If I want to run a stereo rig (No, middle Dry cab), then I connect a Hotplate between the Amp Selector and the DRY speaker cab, and set it to load.
The setup is a WD/D/WD setup, which allows me to choose to put the Dry signal into the wet cabs or not, allowing W/D/W, or if I only use 1 wet Cab, then it's W/D, and/or WD/D. I used (3) 4x12 cabs loaded w/ Celestion/Hellatone G12-H30's.
The the RSB18R (R=Rack) (F=Foot Controller) is only a switchable patchbay. To do what I'm doing, you'd need to add a CAE or similarly spec'd Amp Selector-- there are only a few manufacturers producing them. CAE, Skrydstrup R&D, Egnater used to make one, and I believe Mark L makes a similar one for up to 3 amps... (Not sure on that).
I tend to use tones ranging from Vintage Classic Rock 60's/70's, to 80's Metal, to Fusion Jazz, Funk, R&B, Pop and Blues tones, ranging from BB King to Gary Moore. I designed this rig the way I did, because I wanted to be free to use a variety of different amps for my core sounds, but have a way to utilize my preferred studio quality rack gear, and classic & preferred pedals with whichever amp I selected (in Real time), while not destroying the fundamental Core amp sound, UNLESS wanting to do so intentionally- for affect.
Hope that helps,
Zach
